Product Features
• Low-power thermal network core with good image quality.
• Cost-effective SOC design for compact integration.
• Built-in fire point detection, temperature alarm and perimeter
intelligence.
• Supports SDK, HTTP and ONVIF for secondary development.
Key Specifications
• Detector: VOx uncooled infrared FPA
• Resolution: 256 x 192
• Pixel pitch: 12 um
• Spectral range: 8-14 um
• NETD: <=50 mK (@F1.0, 300K)
• Video stream: H.264 main stream, 720 x 576 @25 fps
• Temperature range: -20℃ to +150℃; 0℃ to +550℃
• Accuracy: +/-2℃ or +/-2%, whichever is greater
• Power: 9-14 V DC, typical 0.7 W
• Interfaces: RJ45, RS232/RS485, alarm I/O
• Size/weight: 35 x 35 x 35.5 mm, approx. 55.5 g
• Protocols: SDK (Windows/Linux), HTTP, ONVIF
Applications:
Security monitoring, industrial temperature monitoring, robotics and firefighting.
