Product Features
• Compact network thermal core with low power consumption and
clear image quality.
• Built-in fire point detection, temperature alarm and perimeter
intelligence.
• Multiple lens options for temperature measurement and observation
scenarios.
• SDK, HTTP and ONVIF support for easy system integration.
Key Specifications
• Detector: VOx uncooled infrared FPA
• Resolution: 384 x 288
• Pixel pitch: 17 um
• Spectral range: 8-14 um
• NETD: <=40 mK (@F1.0, 300K)
• Video stream: H264 main stream, 720 x 576 @25 fps
• Temperature range: -20℃ to +150℃; 0℃ to +550℃
• Accuracy: +/-2℃ or +/-2%, whichever is greater
• Power: 9-14 V DC, typical 0.9 W
• Interfaces: RJ45, RS232/RS485, alarm I/O
• Size/weight: 38 x 38 x 39 mm, approx. 85.5 g
• Protocols: SDK (Windows/Linux), HTTP, ONVIF
Applications:
Security monitoring, industrial temperature monitoring, robotics and firefighting.
